Osteosynthesis Removal Post Orthognathic Surgery: An Omani Experience

  1. Home
  2. Articles

Osteosynthesis Removal Post Orthognathic Surgery: An Omani Experience



Ali Al Mashaikhi1*, Mohammed Al Nabhani2,Mahmood H Al Salmi2, Said Al Rashdi3, AfrahAl Jabri4

1Resident in Oral & Maxillofacial Surgery, Oman Medical Specialty Board, Oman

2Senior Consultants, Oral & Maxillofacial Surgeon, Al Nahdha Hospital, Oman

3Specialist, Oral & Maxillofacial Surgery, Al Nahdha Hospital, Oman

4Dental Surgeon, Al Nahdha hospital, Oman

*Corresponding author: Ali Al Mashaikhi, Resident in Oral & Maxillofacial Surgery, Oman Medical Specialty Board, Oman.

Citation: Mashaikhi AA, Nabhani MA,Salmi MHA, Rashdi SA, Jabri AA. (2020) Osteosynthesis Removal Post Orthognathic Surgery: An Omani Experience. JOral Med and Dent Res. 1(1):1-9.

Received: July 21, 2020 | Published: August 7, 2020

Copyright© 2020 by Mashaikhi AA, et al. All rights reserved. This is an open access article distributed under the terms of the Creative Commons Attribution License, which permits unrestricted use, distribution, and reproduction in any medsssium, provided the original author and source are credited.



Abstract

Abstract

Objective
This study was designed to determine the prevalence and the risk factors led to osteosynthesis removal post orthognathic surgery in Oman and to compare between Omani population and international populations.

Methods

The study was conducted in patients who underwent orthognathic surgery between the years 2010 to 2015. Data collected from the Al Nahdha hospital in Oman. Different factors were investigated using statistical tools.

Results
There was a total of 319 patients who were investigatedin this study. Among these patients 42.3% were males while 57.1% were females. Different factors were identified that led to the removal of the oseosynthesis. Eight and half percentage of the study sample had some osteosynthesis removed. Local infections around the hardware was the highest (4.4%) followed by pain complaining (2.8%) of all cases.

Conclusion
Infection prevalence in patients with orthognathic surgeries was reported to bevery low, however it is the main reason for the removal of osteosynthesis. Highest percentage (44%) of bone plates were removed from mandibular osteotomy sites.

Keywords

Orthognathic; Osteosynthesis; Hardwarefixation; Bone plates; Screws

Introduction

Different surgical techniques of orthognathic were introduced to treat maxillofacial deformities [1]. Orthognathic surgery is a corrective surgical procedure that corrects jaw and facial abnormalities that are secondary to growth disturbance, congenital abnormality and trauma. There are various forms of miniplates and screws used in osteosynthesis that could be utilized in the Maxillofacial skeleton during the orthognathic surgeries [2,3]. This method nowadays is increasingly used to fix and strengthen the bone segments [4].

Some mini plates used in some cases are necessary to be removed [5, 6]. There are somecomplications, which are associated with the orthognathic surgery; including the routine surgical complications like infection and swelling. The characteristics of patients requiring the removal of plate were analyzed in addition to the number and location in which the bone plate was removed [7]. The main purpose of the study is to comparatively examine the prevalence and risk factors that are associated with the removal of bone platespost orthognathic surgery in Omani patients. In addition, acomparison betweenOmani patients and international patients were done in this study. This will be helpful to develop interventions that are highly helpful to overcome the clinical complication.

Research Rationale

This study focused the prevalence and risk factors in Omani patients and compares it with international population. There is no such study conducted previously by any researcher in our region. Therefore, this is considered to be unique research.

Methods
In this study clinical record of 319 patients were collected from the electronic data information system from AlNahdha hospital. Both male and female patients were investigated. AlNahdha hospital is the main hospital in the country which performs orthognathic surgeries. This study included who were operated in the period from 1st Jan 2010 to October 2015 with two years minimum followup.According to the observation, there were different variables that were set and examined individually. The data was further analyzed using excel program and SPSS [8].Different statistical calculations were carried out using these statistical software’s. In addition, different positively related factors to bone plate removal that were reported in Omani patients were investigated. Statistical analysis was done in terms of duration of surgery, time post initial placement of the hardware, relationship between plate removal and the characteristics of patients required to remove the plates. Moreover, more analysis was carried out to find the association between characteristics of patients requiring plate removal and the location in which the plates were removed. Complications of surgery as well as reason of the plate removal were also investigated in this study.

Results

Proper investigation of Omani patients on the basis of data collected from the Al Nahdha hospital. According to the observed results, patients with orthognathic surgery and need a bone plate and screws removal showed that 50.2 % of the patients were below 25 year old and 44.8% of the patients were between 25 to 34 year old while the remaining 4.4% of the patients were above 35 year. Both males and female patients were investigated in this study, in which 42.3% were males while 57.1% were females. The study foundthat37.0% of the patients were reported with one bone plate and screws removal and 33.3% of the patients were reported with removal of two bone plates and screws. In our study the results revealed removing 3 bone plates and screws was 3.7% of patients, while we observed 11.1% of the patient with 4 bone plates and screws removed and a total of 14.8 % of the patients with all bone plates and screws.

Further investigation on the basis of the need for plate removal reported that most of the patients requiring bone plate removal were less than 25 years of age. The number of patients who were more than 25 years old were 150, in which (93.8 %) of the bone plates placed were not removed while (6.2 %) of the patients required removal. The number of patients who were in the age group between25 and 34 were 127. Most of them, (88.8%) did not required bone plate removal, while (11.2%) required removal. Patients above the age of 45 years mostly did not require bone plate removal with a percentage of (7.1%). There were some surgical complications associated with patients undergone the surgery. According to our observation 93.8% of the patients did not report any complications while 6.6% of the patients reported surgical complications. In addition, this study found that the prevalence of bone plate was observed in 8.5% of the patients.

In association to the time after initial placement of the bone plate, the removal of these bone plates and screws were reported at the mean of 11.4 months and the median time observed was 9 months. It was observed that some patients have different location of plate removal, in which 3.7 % of the patients were reported to remove plate from the chin post genioplasty procedure. The highest percentage of the patients reported a removal of plate from the mandible location with 44.4%, while 33.3% of the patients the hardware was removed from the Maxilla. In the study it has been reported that highest number of surgeries for bone plate removal were conducted in the year 2013 and 2014 with a percentage of 23.2% to 28.8% respectively.

There are different factors that are associated with bone plate removal. According to the observed results 3.7% of the patient’s bone plates were removed due to the exposure and bone resorption. Nonetheless, 51.9% of the patients in this case were reported to remove bone plate due the infections after surgery while 33.3% of the patients reported to remove bone plate due to severe pain.Additionally, 7.4% of the patient’s bone plates were removed due to the fact that the plates were palpable. Statistical analysis revealed that the study was not statistically significant in relation to the age and gender of the patients with a p value of 0.301 and 0.071 respectively. The mean value of age was 25.22 and median was 24.00 while 5.497 was the observed standard deviation (Table 1-Table 10).

N

Valid

317

Missing

2

Mean

25.22

Median

24

Standard Deviation

5.497

Minimum

16

Maximum

52

Table 1: Age.

Age categories

Frequency

Percent

Valid Percent

<25 years

160

50.2

50.5

25 - 34 years

143

44.8

45.1

>=35 years

14

4.4

4.4

Total

317

99.4

100

Missing

System

2

0.6

 -

Total

319

100

Table 2: Age categories.

Male

Frequency

Percent

Valid Percent

Female

135

42.3

42.6

Total

182

57.1

57.4

Missing

System

317

99.4

100


Total

2

0.6

319

100


Table 3: Gender.



Age

Removed

Not removed

p value

n (%)

n (%)

<25 years

10 (6.2)

150 (93.8)

0.301

25-34 years

16 (11.2)

127 (88.8)

>=35 years

1 (7.1)

13 (92.9)

Sex

7 (5.2)

128 (94.8)

0.071

Male

Table 4: Characteristics of patients requiring plate removal.

No

Frequency

Percent

298

93.4

Yes

21

6.6

Total

319

100

Table 5: Complications during the surgery.


No

Frequency

Percent

292

91.5

Yes

27

8.5

Total

319

100

Table 6: Outcome-Bone plate removal.


N

Valid

27

Missing

292

Mean

11.44

Median

9

Standard Deviation

8.684

Minimum

1

Maximum

34

Table 7: Time to plate removal (months).


LA

Frequency

Percent

Valid Percent

11

3.4

40.7

GA

16

5

59.3

Missing

Total

27

8.5

100

System

292

91.5



Total

319

100

Table 8: Percentage.


Genio

Frequency

Percent

Valid Percent

1

0.3

3.7

Mandible

12

3.8

44.4

Maxilla

9

2.8

33.3

Mandible &Genio

1

0.3

3.7

Maxilla &Genio

2

0.6

7.4

Maxilla & Mandible

2

0.6

7.4

Total

27

8.5

100

Missing

System

292

91.5



Total

319

100



Table 9: Location of the plate removal.


Bone resorption

Frequency

Percent

Valid Percent

1

0.3

3.7

Exposed

1

0.3

3.7

Infection

14

4.4

51.9

Pain

9

2.8

33.3

Palpable

2

0.6

7.4

Total

27

8.5

100

Missing

System

292

91.5



Total

319

100


Table 10: Cause of the removal.


1

Frequency

Percent

Valid Percent

10

3.1

37

2

9

2.8

33.3

3

1

0.3

3.7

4

3

0.9

11.1

5

4

1.3

14.8

Total

27

8.5

100

Missing

System

292

91.5



Total

319

100


Table 11: Number of hardware removed.

Discussion

Patients who undergo orthognathic surgeries are highly associated with different number of complications. These complications are depending on different factors which are highly influencing the surgical outcome and the rate which is associated with bone plate removal [9]. There were also different types of complications that could take place after exposing the patient for a second procedure for bone plate removal. However, the fixation of the plate by Osteosynthesis consider as the most safe and reliable procedure [10].

According to our results, the majority of the plate removal was due to infections. These results were contradictory with the published literature in which about 13.7% of the plates placed for orthognathic surgery were removed due to recurrent infections episodes [11]. The average time of the removal of the hardware in our studied samples was 11.4 months; these would seem acceptable since most of bone healing have already taken place. Previous studies conducted reported the average of 9.9 months duration until removal of hardware. These studies also reported 79.65%of the patients had their plates removed within the first year after placement [12]. In the case of results obtained by our observations, majority of the patients were young, in which more than half (50.2%) of the patients were below 25 year old. According to the previously study conducted by Yang et al. [13] in which same results were observed as the most of the patients in this study was below 30 years old [13].

According to the results reported in the literature in majority of the cases the removal of 2 plates per sides was done which may cause high risk among the patients were involved in the particular illness [14]. Majority of the patients were observed in our studies with only one bone plates and screws replacement following by (33.3%) were reported to remove two bone plates and screws. Surgical complications are also associated in the patients with post orthognathic complication in our study only 6.6% of the patients were involved in post-surgical complications. These results are contradictory with the previously reported literature. According to the Davis et al. [15] there are several numbers of evidences regarding the post-surgical complications were associated with the patients with post orthognathic surgery complications [15]. Highest number of surgeries reported in the year 2013 and 2014 in Oman. While similar results were reported in another country but in different era. The reported results in the number of plate removal cases were increased in patients in the year 2004 to 2007 [16].

Conclusion

After the proper data collection and analyzing the collected data, it has been found that,Othognathic surgeries carried in Al Nahdha Hospital has low percentage of post surgery complications that need to remove the osteosynthesis. The most appeared reason for the bone plate’s removal was found to be the local infections followed by pain and palpability.The data shows the osteosynthesis removal was more in females and the middle age category of 25 to 34. Our findings are comparable to that reported in the literature. Further studies are advised to investigate the reasons of such infections and the commonality to happen in mandibular region.

References

  1. Robl MT, Farrell BB, Tucker MR. (2014) Complications in orthognathic surgery: a report of 1000 cases Oral Maxillofac Surg Clin. 26(4):599-609.
  2. Kim YI, Jung YH, Cho BH, Kim JR, Kim SS, et al. (2010) The assessment of the short- and long-term changes in the condylar position following sagittal split ramus osteotomy (SSRO) with rigid fixation. J Oral Rehabil. 37(4):262-70.
  3. Alpha C, O’Ryan F, Silva A, Poor D. (2006) The incidence of postoperative wound healing problems following sagittal ramus osteotomies stabilized with miniplates and monocortical screws. J Oral Maxillofac Surg. 64(4):659-68.
  4. Rustemeyer J, Gregersen J. (2012) Quality of Life in orthognathic surgery patients: Post-surgical improvements in aesthetics and self-confidence. J Cranio-Maxillofacial Surg. 40(5):400-4.
  5. Zingler S, Hakim E, Finke D, Brunner M, Saure D, et al. (2017) Surgery-first approach in orthognathic surgery: Psychological and biological aspects- A prospective cohort study. J Cranio-Maxillofacial Surg. 45(8):1293-301.
  6. Magro-Filho O, Goiato MC, Oliveira DTN, Martins LP, Salazar M, et al. (2015) Evaluation of patients’ satisfaction after class III orthognathic surgery. J Clin Diagnostic Res. 9(10):ZC23.
  7. Lloyd T, Pabla R, Sharma S, Hunt N. (2015) Orthognathic Surgery. In: Plastic and Reconstructive Surgery: Approaches and Techniques. 26:279.
  8. Olate S, Sigua E, Asprino L, De Moraes M. (2018) Complications in OrthognathicSurgery. J Craniofac Surg. 29(2):e158-61.
  9. Kim YK. (2017) Complications associated with orthognathic surgery. J Korean Assoc Oral Maxillofac Surg. 43(1):3-15.
  10. Farrell BB, Franco PB, Tucker MR. (2014) Virtual surgical planning in orthognathic surgery. Oral Maxillofac SurgClin North Am. 26(4):459-73.
  11. Bauer RE, Ochs MW. (2014) Maxillary orthognathic surgery. Oral Maxillofac Surg Clin North Am. 26(4):523-37.
  12. Peiró-Guijarro MA, Guijarro-Martínez R, Hernández-Alfaro F. (2016) Surgery first in orthognathic surgery: A systematic review of the literature. American Journal of Orthodontics and Dentofacial Orthopedics. 149(4):448-62.
  13. Yang L, Xiao YD, Liang YJ, Wang X, Li JY, et al. (2017) Does the Surgery-First Approach Produce Better Outcomes in Orthognathic Surgery? A Systematic Review and Meta-Analysis. J Oral Maxillofac Surg. 75(11):2422-9.
  14. Sukegawa S, Kanno T, Manabe Y, Matsumoto K, SukegawaTY, et al. (2018)Is the removal of osteosynthesis plates after orthognathic surgery necessary? Retrospective long-term follow-up study. Int J Oral Maxillofac Surg. 47(12):1581-6.
  15. Wermker K, Kleinheinz J, Jung S, Dirksen D. (2014) Soft tissue response and facial symmetry after orthognathic surgery. J Cranio-Maxillofacial Surg. 42(6):e339-45.
  16. Davis CM, Gregoire CE, Steeves TW, Demsey A. (2016) Prevalence of surgical site infections following orthognathic surgery: A retrospective cohort analysis. J Oral Maxillofac Surg. 74(6):1199-206.

.
